SY12M-FX-BK

Regular price$239.00
/
Shipping calculated at checkout.
Mount

Model: SY12M-FX-BK

UPC: 0-84438-76292-1

Focal Length: 12mm

Maximum Aperture: F2.0

Coverage: APS-C/Four Thirds

Optical Construction: 12 Glass Elements In 10 Groups

Aperture Range: F2.0 to F22

Diaphragm Blades: 6

Coating: Nano Coating System

Minimum Focusing Distance: 7.87” (0.2m)

Filter Size: 67mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.85” (72.5mm)

Weight: 9.17oz (260g)

Length: 2.32” (59.0mm)

Model: SY12M-FX-SIL

UPC: 0-84438-76296-9

Focal Length: 12mm

Maximum Aperture: F2.0

Coverage: APS-C/Four Thirds

Optical Construction: 12 Glass Elements In 10 Groups

Aperture Range: F2.0 to F22

Diaphragm Blades: 6

Coating: Nano Coating System

Minimum Focusing Distance: 7.87” (0.2m)

Filter Size: 67mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.85” (72.5mm)

Weight: 9.17oz (260g)

Length: 2.32” (59.0mm)

Model: SY12M-MFT-BK

UPC: 0-84438-76293-8

Focal Length: 12mm

Maximum Aperture: F2.0

Coverage: APS-C/Four Thirds

Optical Construction: 12 Glass Elements In 10 Groups

Aperture Range: F2.0 to F22

Diaphragm Blades: 6

Coating: Nano Coating System

Minimum Focusing Distance: 7.87”(0.2m)

Filter Size: 67mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.85”(72.5mm)

Weight: 8.99oz (255g)

Length: 2.28” (57.9mm)

Model: SY12M-MFT-SIL

UPC: 0-84438-76297-6

Focal Length: 12mm

Maximum Aperture: F2.0

Coverage: APS-C/Four Thirds

Optical Construction: 12 Glass Elements In 10 Groups

Aperture Range: F2.0 to F22

Diaphragm Blades: 6

Coating: Nano Coating System

Minimum Focusing Distance: 7.87”(0.2m)

Filter Size: 67mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.85”(72.5mm)

Weight: 8.99oz (255g)

Length: 2.28” (57.9mm)

Model: SY12M-E-BK

UPC: 0-84438-76291-4

Focal Length: 12mm

Maximum Aperture: F2.0

Coverage: APS-C/Four Thirds

Optical Construction: 12 Glass Elements In 10 Groups

Aperture Range: F2.0 to F22

Diaphragm Blades: 6

Coating: Nano Coating System

Minimum Focusing Distance: 7.87”(0.2m)

Filter Size: 67mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.85”(72.5mm)

Weight: 8.64oz (245g)

Length: 2.33” (59.1mm)

Model: SY12M-E-SIL

UPC: 0-84438-76295-2

Focal Length: 12mm

Maximum Aperture: F2.0

Coverage: APS-C/Four Thirds

Optical Construction: 12 Glass Elements In 10 Groups

Aperture Range: F2.0 to F22

Diaphragm Blades: 6

Coating: Nano Coating System

Minimum Focusing Distance: 7.87”(0.2m)

Filter Size: 67mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.85”(72.5mm)

Weight: 8.64oz (245g)

Length: 2.33” (59.1mm)

​The Samyang 12mm f/2.0 NCS CS Lens is a prime wide-angle lens designed specifically for use with APS-C sized image sensors. Providing a 35mm-equivalent focal length of 18mm and a broad 98.9° angle of view, this lens is well-suited for architectural, interior, and landscape images. Its fast f/2.0 maximum aperture is further beneficial to working in low-light conditions.

Three extra-low dispersion elements and two aspherical elements have been incorporated into the optical design to minimize chromatic aberrations and distortion in order to produce sharper images. Additionally, a Nano Coating System (NCS) has been applied to the lens elements in order to reduce surface reflections and prevent lens flare and ghosting for improved light transmission and more contrast-rich imagery.

  • Prime wide-angle lens provides a 35mm-equivalent focal length of 18mm, making it ideally suited for architectural and landscape subjects.
  • Fast f/2.0 maximum aperture benefits working in low-light conditions.
  • Three extra-low dispersion elements and two aspherical elements reduce chromatic aberrations and distortions in order to produce sharper images.
  • Nano Coating System improves light transmission and suppresses lens flare and ghosting for more contrast-rich, color-neutral images.

User Manual Download

Specifications

SPECIFICATIONS12mm F2.0 NCS CS
APERTURE RANGEF2.0 ~ 22
OPTICAL CONSTRUCTION12 ELEMENTS IN 10 GROUPS (2 ASPHERICAL LENS)
MINIMUM FOCUSING DISTANCE0.2m (7.87")
FILTER SIZEΦ67.0mm
MAXIMUM DIAMETERΦ72.5mm
MOUNTFujifilm XSony EMicro 4/3
ANGLE OF VIEWASP-C98.9˚98.9˚-
FOUR-THIRDS 4/3”--83.0˚
LENGTH (mm)59.4mm59.1mm57.9mm
WEIGHT (g)260g245g255g

MTF Chart

Optical Construction

Features

Bright F2.0 Aperture

Guarantees faster shutter speed in low light conditions and adds depth to your pictures by blurring the background.

Aspherical Lens

With minimal spherical aberration and distortion, you can take pictures with incredible precision.

Nano-Coating System

The nano-coating system minimizes flare and ghosting effect resulting in crystal clear image quality.

Beautiful Bokeh with 6 Aperture Blades

Featuring 6 rounded blades, it adds an artistic touch to your pictures and creates a sense of soft dimension with incredible bokeh, perfect for out-of-focus portraits and night city landscapes.

Compact & Lightweight

The compact, lightweight build makes it the perfect choice when traveling.

Smooth Focus Ring

Smooth focusing ensures precise control and produces images with incredible sharpness, making it the ideal choice for indoor and night shooting.
