SY300M-FX-BK

Regular price$259.00
/
Shipping calculated at checkout.
Mount

Model: SY300M-M-BK

UPC: 0-84438-76153-5

Focal Length: 300mm

Maximum Aperture: F6.3

Coverage: APS-C/Four Thirds

Optical Construction: Reflex Mirror (Catadioptric) 9 Glass Elements in 9 Groups

Aperture Range: F6.3 FIXED

Diaphragm Blades: n/a

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 2.95ft(0.9m)

Filter Size: 58mm/25.5mm

Lens Hood: Removable

Maximum Diameter: 2.54” (64.5mm)

Weight: 11.2oz (318g)

Length: 2.90” (73.7mm)

Model: SY300M-FX-BK

UPC: 0-84438-76159-7

Focal Length: 300mm

Maximum Aperture: F6.3

Coverage: APS-C/Four Thirds

Optical Construction: Reflex Mirror (Catadioptric) 9 Glass Elements in 9 Groups

Aperture Range: F6.3 FIXED

Diaphragm Blades: n/a

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 2.95ft(0.9m)

Filter Size: 58mm/25.5mm

Lens Hood: Removable

Maximum Diameter: 2.54” (64.5mm)

Weight: 11.1oz (316g)

Length: 2.92” (7.4.1mm)

Model: SY300M-MFT-BK

UPC: 0-84438-76155-9

Focal Length: 300mm

Maximum Aperture: F6.3

Coverage: APS-C/Four Thirds

Optical Construction: Reflex Mirror (Catadioptric) 9 Glass Elements in 9 Groups

Aperture Range: F6.3 FIXED

Diaphragm Blades: n/a

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 2.95ft(0.9m)

Filter Size: 58mm/25.5mm

Lens Hood: Removable

Maximum Diameter: 2.54” (64.5mm)

Weight: 11.1oz (311g)

Length: 2.86” (72.6mm)

Model: SY300M-E-BK

UPC: 0-84438-76157-3

Focal Length: 300mm

Maximum Aperture: F6.3

Coverage: APS-C/Four Thirds

Optical Construction: Reflex Mirror (Catadioptric) 9 Glass Elements in 9 Groups

Aperture Range: F6.3 FIXED

Diaphragm Blades: n/a

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 2.95ft(0.9m)

Filter Size: 58mm/25.5mm

Lens Hood: Removable

Maximum Diameter: 2.54” (64.5mm)

Weight: 11.2oz (318g)

Length: 2.91” (73.8mm)

The Samyang 300mm F6.3 UMC CS Lens is a mirror lens designed specifically for use on mirrorless cameras. The lens' Cassegrainian design enables it to achieve a 450mm 35mm-equivalent focal length perspective within a compact and lightweight lens design that is significantly smaller than a traditional 300mm lens. It features a fixed f/6.3 aperture and utilizes manual focus operation for focusing as closely as 2.95'.

One extra-low dispersion element and the inherent mirror construction of the lens work to eliminate chromatic aberrations while providing notable image sharpness and clarity. Furthermore, the UMC (Ultra Multi Coated) coating has been applied to reduce surface reflections, lens flare, and ghosting while also contributing to improved overall contrast.

  • Mirror lens designed specifically for mirrorless cameras.
  • Catadioptric system with Cassegrainian design helps to reduce the overall size of the lens while still providing a 35mm-equivalent focal length of 450mm.
  • One extra-low dispersion element and a UMC coating are integrated into the lens construction to improve sharpness and clarity as well as enhance the overall image contrast.

    User Manual Download

    Specifications

    SPECIFICATIONS300mm F6.3 ED UMC CS
    APERTURE RANGEF6.3 FIXED
    OPTICAL CONSTRUCTION9 ELEMENTS IN 9 GROUPS
    MINIMUM FOCUSING DISTANCE0.9m (2.95ft)
    FILTER SIZEΦ25.5mm (REAR)
    MAXIMUM DIAMETERΦ64.5mm
    MOUNTCanon MFujifilm XSony EMicro 4/3
    ANGLE OF VIEWASP-C5.1˚5.4˚5.4˚-
    FOUR-THIRDS 4/3”---4.2˚
    LENGTH (mm)73.7mm74.1mm73.8mm72.6mm
    WEIGHT (g)318g316g318g311g

    MTF Chart

    Optical Construction

    Features

    Minimized Flare and Ghost Effects with Ultra Multi Coating

    By reducing the impact of flares and ghosting effects in your pictures while ensuring excellent image quality and contrast from the center to the periphery, it offers crystal clear, sharp image quality.

    Compact & Lightweight

    The compact, lightweight build makes it the perfect choice when traveling.

    Smooth Focus Ring

    Smooth focusing ensures precise control and produces images with incredible sharpness, making it the ideal choice for indoor and night shooting.

    Reflex Mirror Lens

    The short barrel adds to convenience while the unique donut-shape bokeh makes images even more attractive.

    Sample Gallery
